Back-illuminated higher sensitivity , high-speed , mid-wave infrared detector

    Item Description

    For purchase and shipment only in North America (USA, Canada, Mexico).  Please contact your local Hamamatsu office in other countries.

    Sensitive, room temperature 0.7x0.7 mm MWIR detector.  Detector is a RoHS compliant InAsSb device, and can directly replace detectors containing lead, mercury, or cadmium. The back illuminated detector is packaged in a ceramic SMD.

    Applications include gas sensing, radiation thermometers and flame detection.

    Features

    • High sensitivity
    • High-speed response
    • High shunt resistance
    • RoHS compliant (lead, mercury, cadmium free)

      Please contact us to discuss your specific needs and to ensure you have selected the best detector for your measurement needs.  boselec@boselec.com  +1-617-566-3821

        Product Technical Specs

        • Summary product specifications are below
        • View and download the detailed product sheet at the Download PDF tab
        • Please contact us with any questions for or assistance via our contact request page or at 617-566-3821
         Detector
        Part Number P16612-011CA
        Type Photovoltaic InAsSb detector
        Cutoff Wavelength 5.3um
        Peak wavelength 4.1um
        Cooling Room temperature
        Detectivity D* = 10E9
        Rise time 15ns
        Detector Size 0.7 x 0.7 mm2
        Field of View (FoV) 86 degrees
        Package SMD
