High-speed , high sensitivity mid-wave infrared detectors

    Item Description

    Note: Hamamatsu P13243 series detectors have gone end of life.  Only our remaining inventory can be purchased, there are no orders avaible from the factory for these parts.

    This item is for purchase and shipment only in North America (USA, Canada, Mexico).  Please contact your local Hamamatsu office in other countries.

    Sensitive, room temperature 0.7x0.7 mm MWIR detector.  Detector is a RoHS compliant InAsSb device, and can directly replace detectors containing lead, mercury, or cadmium. They are packaged in a TO-46 housing.

    For an SMD packaged variant of this detector we recommend the P16612-011CA

    Applications include gas sensing, radiation thermometers and flame detection.

    Features

    • High sensitivity
    • High-speed response
    • High shunt resistance
    • RoHS compliant (lead, mercury, cadmium free)

      Please contact us to discuss your specific needs and to ensure you have selected the best detector for your measurement needs.  boselec@boselec.com  +1-617-566-3821

        Product Technical Specs

        • Summary product specifications are below
        • View and download the detailed product sheet at the Download PDF tab
        • Please contact us with any questions for or assistance via our contact request page or at 617-566-3821
         Detector
        Part Number P13243-011MA (TO-46)
        Type Photovoltaic InAsSb detector
        Cutoff Wavelength 5.3um
        Peak wavelength 4.1um
        Cooling Room temperature
        Detectivity D* = 10E9
        Rise time 6ns
        Detector Size 0.7 x 0.7 mm2
        Field of View (FoV) 90 degrees
        Package TO-46 or SMD
